Best Seller33
1.5-2.0 Inch Light Grey PVC Plug In Stem Caster Wheels (35-35kg)
Step 1: Mounting Style
Rigid
✓
Swivel Plate
✓
Threaded Stem
✓
Bolt Hole
✓
Swivel Stem
✓
Stem Ring
✓
Expanding Stem
✓
Others
✓
Step 2: Wheel Diameter
2“(50mm)
8 Core Advantages of Dual Material Option Bolt Hole Stem Furniture Casters
- Smooth Swivel — Two Material Options: Precision plain bore design ensures smooth, quiet rotation. Choose PVC+PP for cost-effective performance or PA+Nylon for maximum durability.
- Premium Wheel — PVC or PA (Nylon): PVC (Polyvinyl Chloride): cost-effective, non-marking, quiet on hard floors. PA (Nylon): highest hardness (70 Shore D), superior wear resistance for high-frequency use.
- Bolt-Hole Stem Mount: Standard M11×22 bolt-hole stem design. Insert stem into equipment mounting hole for quick, secure installation. Compatible with standard furniture mounting holes.
- Housing Options — PP or PA (Nylon): PP (Polypropylene): lightweight, chemical-resistant, economical. PA (Nylon): superior impact resistance, tough, ideal for heavy-use furniture.
- Furniture-Grade Design: Engineered specifically for office and home furniture. Both material options provide quiet operation and smooth rolling on hard surface floors.
- Consistent Quality: Strict QC processes ensure consistent performance. Each caster is load-tested and rotation-tested before shipment.
- Wide Application Temperature Range: PVC: -20°C to +60°C. PA (Nylon): -40°C to +120°C — withstands higher temperatures for demanding environments.
- Flexible Material Choice: Two distinct material combinations for different use cases — select PVC+PP for budget-friendly daily use, PA+Nylon for premium high-frequency applications.
Detailed Technical Properties
| Wheel Material | PVC+PP / PA (Nylon)+PA |
|---|---|
| Wheel Hardness | PVC: 85±5 Shore A / PA: 70 Shore D |
| Housing Material | PP / PA (Nylon) |
| Bearing Type | Plain Bore |
| Stem Type | Bolt Hole — M11×22 (Type J) |
| Swivel Angle | 360° |
| Operating Temperature | PVC: -20°C ~ +60°C / PA: -40°C ~ +120°C |
| Floor Protection | Excellent — Non-marking, Floor-friendly |
| Noise Level | Low — Quiet rolling on hard surfaces |
| Housing Finish | PP Housing (RoHS compliant) |
Downloads
Applications
Suitable Industries & Applications
Office Chairs & Workstations
Home Furniture & Seating
Retail Display Fixtures
Hotel & Hospitality Furniture
Conference & Meeting Room Furniture
Library & Study Furniture
Salon & Spa Equipment
Reception & Lobby Furniture
Educational & Institutional Furniture
Light Duty Mobile Carts
Entertainment & Media Stands
Portable Office Equipment
Recommended Usage
Suitable
Smooth, hard floors (tile, concrete, vinyl)
Suitable
Indoor environments
Suitable
Intermittent to moderate use
Suitable
Equipment under 115 kg total (4 casters)
Not Recommended
Rough outdoor terrain or gravel
Not Recommended
Continuous heavy-duty industrial use
Not Recommended
High-temperature (>60°C) environments
Not Recommended
Exposure to strong acids or solvents
FAQ
Q: What is the minimum order quantity? Can I order samples first?
A: Our standard MOQ is 100 pieces per model. Sample orders are welcome — you can order 1–2 pieces for testing before placing a bulk order.
Q: Can I customize the wheel color or bracket finish?
A: Yes! We offer full OEM/ODM customization. You can choose custom wheel colors, bracket finishes, and even branded packaging with your logo. Custom orders have their own MOQ — contact us for details.
Q: Will these casters scratch or leave marks on my floors?
A: Not at all. Our PVC wheels are non-marking and floor-friendly. They roll smoothly and quietly on tile, concrete, vinyl, and other hard surfaces without leaving scuffs or stains.
Q: These have a threaded stem — how do I install them on my equipment?
A: Simply insert the M11×22 bolt-hole stem into the mounting hole on your furniture. No special tools needed — just push and secure.
Q: How do I know this caster can handle my equipment's weight?
A: Each caster supports up to 35 kg individually. For a 4-caster setup, the total safe working load is around 122 kg (safety margin included). Always distribute weight evenly across all casters. If you're unsure, our team can help you pick the right model.
Q: What is the typical lead time for orders?
A: Sample orders ship within 3–5 business days. Standard bulk orders typically take 15–25 days, depending on quantity. Custom orders may take a bit longer — we'll confirm the exact timeline when you order.
Company Profile
SUMATIC CASTER, established in 2020 in Zhongshan City, China, is a global provider of caster solutions, offering over 40 product series and more than 1,000 models. We specialize in high-performance casters for furniture, industrial, medical, and commercial applications, aiming to enhance equipment mobility and user experience.
Manufacturing Facility
Quality Control
Our Certificates
Exhibition
Our Services
Packaging & Shipping
Technical Specifications Table
Common Specifications: Wheel = PVC+PP / PA (Nylon)+PA | Bearing = Plain Bore | Stem Type = Bolt Hole (J)
Stem Mount Models
| Photo | Model | Size | Wheel Diameter | Wheel Width | Load Capacity | Overall Height | Stem Spec | Mounting Type |
|---|---|---|---|---|---|---|---|---|
|
SC3302-J03 | 2.0" | 50 mm | 54 mm | 35 kg | 62 mm | M11×22 mm | Stem Bolt (PVC+PP) |
| SC3302-J05 | 2.0" | 50 mm | 54 mm | 35 kg | 62 mm | M11×22 mm | Stem Bolt (PA+Nylon) |
Type D = Thread Stem (Swivel) | Type E = Thread Stem with Brake (Swivel + Brake)
Scroll horizontally to see all specifications
